参数名称 |
单位 |
YZC30 |
YZC30 |
YZC30 |
YZC30 |
YZC30 |
YZC30 |
YZC30 |
YZC30 |
YZC30 |
|
公称力 Rated pressure |
KN |
100 |
250 |
400 |
630 |
1000 |
1600 |
2500 |
5000 |
6300 |
|
液体最大工作压力Max.working pressure |
MPA |
12.5 |
20 |
25 |
25 |
25 |
25 |
25 |
25 |
25 |
|
滑块至工作台最大距离Max.distance between slide and surface of table |
MM |
400 |
630 |
630 |
750 |
800 |
900 |
1000 |
1000 |
1000 |
|
滑块最大行程 Max.stroke of slide |
MM |
400 |
500 |
500 |
500 |
500 |
500 |
500 |
600 |
600 |
|
滑块最大下行速度 Max.down speed of slide |
MM |
50 |
≥35 |
40 |
30 |
24 |
≥20 |
≥20 |
≥20 |
≥20 |
|
滑块最大回程速度Max.return speed of slide |
MM/S |
80 |
≥85 |
80 |
70 |
50 |
≥80 |
≥70 |
≥70 |
≥70 |
|
工作速度Working speed |
MM/S |
25 |
17 |
20 |
15 |
12 |
10 |
10 |
10 |
10 |
|
喉深Throat depth |
MM |
≥210 |
320 |
320 |
320 |
320 |
360 |
325 |
500 |
500 |
|
工作台有效尺寸 Effective area of table |
MM |
410X420 |
510X580 |
560X560 |
630X600 |
710X600 |
800X600 |
850X660 |
1000X900 |
1000X900 |
|
落料孔径The diameter for cutting hole |
MM |
Φ140 |
Φ180 |
Φ200 |
Φ200 |
Φ200 |
Φ200 |
Φ200 |
Φ250 |
Φ250 |
|
左右L-R |
MM |
≈655 |
775 |
1250 |
1600 |
2000 |
2000 |
2200 |
2400 |
2400 |
|
机器外型尺寸 前后 |
MM |
≈1600 |
1480 |
≥1660 |
1750 |
2000 |
2000 |
2000 |
2100 |
2100 |
|
高度Height |
MM |
≈2100 |
2320 |
≥2377 |
2500 |
2650 |
2954 |
3350 |
3820 |
3820 |
|
电功功率 Motor power |
KW |
4 |
5.5 |
7.5 |
7.5 |
11 |
15 |
18.5 |
44 |
44 |
